500A 600A Portable Emergency Power Station lithium Emergency Mobile Power Supply

Product Details

Brand Name: TIANJIN TOEC HUADIAN TECHNOLOGY CO., LTD

Model Number: HD25

Document: Product Brochure PDF

Payment & Shipping Terms

Get Best Price
Highlight:

600A Portable Emergency Power Station

,

Portable Emergency Power Station Lithium

,

Lithium Emergency Mobile Power Supply

Battery Capacity:
16000mAH/20000mAh
Power Features:
TYPE-C Charging Input /PD Output: 5V3A,/9V3A/12V3A/15V3A/20V5A 5V3A/9V3A/12V3A/15V3A,/20V5A USB1: QC3.0/5V3A/9V2A/12V1.5A USB2:5V/2A DC Output: 12V-16.8V8A
Peak Current:
1000A/1200A
LED Lights:
Constant, Strobe, SOS
Shell Flame Retardant Grade:
V0
Operating Temperature:
-30℃-65℃
Product Net Weight:
About 600g
Product Packaging:
Toolbox
Battery Capacity:
16000mAH/20000mAh
Power Features:
TYPE-C Charging Input /PD Output: 5V3A,/9V3A/12V3A/15V3A/20V5A 5V3A/9V3A/12V3A/15V3A,/20V5A USB1: QC3.0/5V3A/9V2A/12V1.5A USB2:5V/2A DC Output: 12V-16.8V8A
Peak Current:
1000A/1200A
LED Lights:
Constant, Strobe, SOS
Shell Flame Retardant Grade:
V0
Operating Temperature:
-30℃-65℃
Product Net Weight:
About 600g
Product Packaging:
Toolbox
500A 600A Portable Emergency Power Station lithium Emergency Mobile Power Supply

We usually export large quantities to foreign countries. Hope to find more trade partners.



High magnification polymer lithium-ion automotive emergency starting power supply



HD25 is a portable, outdoor emergency, and long-lasting automotive emergency power supply that meets American AC power standards. It uses a high magnification polymer lithium-ion battery and is suitable for home emergency power, outdoor travel, emergency relief, and outdoor work.

The battery capacity of this product is16000mAH/20000mAh, using an IC intelligent protection chip that intelligently matches the voltage and current of the car. The nine fold protection is effective (polymer lithium battery, constant current protection, voltage stabilization protection, overshoot protection, anti backflow protection, temperature protection, short circuit protection, overcurrent protection, and over discharge protection) to ensure battery stability. It is suitable for 12V diesel gasoline vehicles, regardless of vehicle type, fearless displacement, bidirectional fast charging, high-power output, and durable. Car refrigerators, car vacuum cleaners, and other car appliances can all be used.



General specifications

General specifications
Built-in battery High rate polymer lithium battery
Battery capacity 16000mAH/20000mAh
Product Features Display &PD&QC3.0&DC output
Power Features

TYPE-C input: 5V/2A/9V2A



USB output: 5V/2A/9V2A/12V-1.5A

Starting current 500A/600A
Peak current 1000A/1200A
LED Lights Constant, Strobe, SOS
lifecycle >1000 times
Fully charged time 3-4H
Shell material PC
Shell Flame retardant grade V0
Operating temperature -40℃-80℃
Product dimension 192*88*44mm(LWH)
Product net weight about 600g
Product color matching Can be freely matched by customers (quantity required)
Product packaging toolbox
Tool box dimension 20.5*22.5*5.5cm (LWH)
Accessories(Default) Intelligent jump cables





note

1. The car cannot be started through continuous ignition or the key cannot be turned

2. It cannot be reversed after every 30 seconds of startup. The two clips cannot be short circuited.

3. Remove the clip within 30 seconds of successfully starting the car.



Violating the above three operations may cause the fuse box of the clip to burn out. Please pay attention to the operation method.



Application

The emergency start power battery is a device that can provide temporary power to a car. When the car battery is low or unable to start, the emergency start power battery can be connected to quickly start the car. Its function is similar to traditional batteries, but it has a larger capacity and can provide greater current output. Suitable for emergency household electricity use, outdoor travel, emergency relief, outdoor work, and other occasions.
