Safe 4000w Inverter 12v Overload Protection And Multiple Protection Functions

Name: Safe 4000w Inverter 12v Overload Protection And Multiple Protection Functions
Brand: TIANJIN TOEC HUADIAN TECHNOLOGY CO., LTD
SKU: HD-I3000W3
Availability: InStock

Product Details

Brand Name: TIANJIN TOEC HUADIAN TECHNOLOGY CO., LTD

Model Number: HD-I3000W3

Document: Product Brochure PDF

Payment & Shipping Terms

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                4000w inverter 12v, 12 volt inverter pure sine wave, inverter 4000w pure sine wave


Output Wave Form:	Pure Sine Wave	Input Voltage:	12V (10-16V)
Efficiency:	90%	Operating Temperature:	-10℃-40℃
Storage Temperature:	-20℃-85℃	Overload Protection:	120%-125%

Output Wave Form:	Pure Sine Wave
Input Voltage:	12V (10-16V)
Efficiency:	90%
Operating Temperature:	-10℃-40℃
Storage Temperature:	-20℃-85℃
Overload Protection:	120%-125%

Safe 4000w Inverter 12v Overload Protection And Multiple Protection Functions

We usually export large quantities to foreign countries. Hope to find more trade partners.

Key Features
Robust Power Output
Peak Power: Ranging from 3000W to 11000W, our inverters can handle even the most demanding loads.
Rated Power: With options from 1500W to 5000W, these inverters provide reliable continuous power output.
Flexible Input Voltage Options
Supports both 12V and 24V input voltages, making it compatible with a variety of battery systems.
Comprehensive Product Output
Delivers clean power through 110VAC & 220VAC outputs along with convenient USB 5V & Type-C 5V ports for charging small devices.
High Efficiency and Protection
Achieves up to 90% efficiency, ensuring optimal energy utilization.
Comes with robust overload protection (120%-125%), safeguarding your equipment from damage.
Intelligent Protection Functions
Low Voltage/High Voltage Protection: Automatically alerts with LED light red and buzzer alarm, followed by automatic recovery.
Overload Protection: Triggers LED light red and buzzer alarm, automatically powers off, requiring manual restart.
High Temperature Protection: Activates LED light red and buzzer alarm, followed by automatic recovery.
Short Circuit Protection: Recovers automatically if the short circuit lasts less than 2 seconds.
Input Reverse Connection Protection: Blows the fuse to prevent damage.

Type	Pure Sine Wave Inverter
Peak Power	3000W	4000W	5000W	6000W	8000W	11000W
Rated Power	1500W	2000W	2300W	3000W	4000W	5000W
Input Voltage	12V & 24V
Product Output	110VAC & 220VAC & USB 5V & TYPE-C 5V
Display	Digital Display
Output Frequency	50HZ±1%/60HZHZ±1%
Output Waveform	Pure Sine Wave
Distorton Rate	THD<3%(Inductive Load)
Efficiency	90%
Input Voltage	12V(10-16V)
Input Voltage	24V(20-32V)
Overload Protectiong	120%-125%
Protection Function	Low voltage: LED light red, buzzer alarm, automatic recovery
	High voltage: LED light red, buzzer alarm, automatic recovery
	Overload: LED light red, buzzer alarm, automatic power off, need to restart
	High temperature: LED light red, buzzer alarm, automatic recovery
	Short circuit(less than 2 seconds); automatic recovery
	Input reverse connection; the fuse is blown
Operating Temperature	-10℃-40℃
Storage Temperature	-20℃-85℃
Operating Height	≤3000m
Product Size(mm)	30615071.5	34815270.6	38515270.6	37621994		475219150
Weight	1.73kg	2.08kg	2.44kg	4.94kg		8.6kg
Product Single Package Size (mm)	350215140	395215140	435215140	435320190		538283228
Product G.W.	2.4kg	2.8kg	3.2kg	6kg		9.6kg

Safe 4000w Inverter 12v Overload Protection And Multiple Protection Functions 0
